Clarksburg, USA - 2020

4 Tanks each 16,7m x 8m including support structure and launder design

SOC TRAN CITY, Vietnam - 2020

2 trickling filters, diameter 24,2 m, ~ 2x 2530 m³ fill folume

Nhlangano, Swaziland - 2019

4 x trickling filter, diameter 20m, ~ 4000 m³ media volume

Menagwins, South-West-Water UK - 2019

1 trickling filter, diameter 35m ~ 4700 m³ media volume

Water purification plant Ingolstadt, Germany 2015/2016 - 3 Trickling filter, each 3500 m³

Zweckverband Zentralkläranlage Ingolstadt
Am Mailinger Moos 145
85055 Ingolstadt



Trickling filter before renovation with random fill media
Removing the loose random fill media
Discharge of 3500m3 within a short time
Plant overview of the trickling filter plant
Installation bottom layer of structured fill media
Installation of the structured fills
Sequential installation of the fill layers
Operational start after reconstruction work using structured fill media

WATER PURIFICATION PLANT LAUBEN - GERMANY

KA LAUBEN (KEMPTEN, 2008)
Abwasserverband Kempten (Allgäu)
Griesösch 1
87493 Lauben

Overview of the water treatment plant with round trickling filter tanks
Installation of bottom layer
Sequential layer installation
Air inlet channel

Installation of structured fill media for water treatment and discharged air treatment of project GKW Kempten

Air inlet channel
Controlbox® - Air inlet channel for good air travel
Installation of water distribution system
Controlbox® - Air inlet channel view from top
Operation of water distribution system

WATER PURIFICATION PLANT OEHRINGEN - GERMANY 2010

KA Öhringen
